Magnetic Separator
Magnetic separators are used to eliminate ferrous materials in the grain during the flowing of the material to protect further equipment damages from metal particles.
Product Enquiry Form
If you have any questions and order request about this product, please contact us.
Product technical information
MODEL
BM 120
Capacity (t/h) Wheat
10
Capacity (t/h) Maize
7
Capacity (t/h) Wheat, maize flour
5
Capacity (t/h) Wheat, maize bran
4
ØD1 (mm)
120
ØD2 (mm)
280
ØD3 (mm)
120
H (mm)
650
Weight (kg)
5
MODEL
BM 150
Capacity (t/h) Wheat
15
Capacity (t/h) Maize
12
Capacity (t/h) Wheat, maize flour
9
Capacity (t/h) Wheat, maize bran
7
ØD1 (mm)
150
ØD2 (mm)
300
ØD3 (mm)
150
H (mm)
650
Weight (kg)
12
MODEL
BM 200
Capacity (t/h) Wheat
40
Capacity (t/h) Maize
30
Capacity (t/h) Wheat, maize flour
20
Capacity (t/h) Wheat, maize bran
10
ØD1 (mm)
200
ØD2 (mm)
300
ØD3 (mm)
200
H (mm)
720
Weight (kg)
23
MODEL
BM 250
Capacity (t/h) Wheat
50
Capacity (t/h) Maize
35
Capacity (t/h) Wheat, maize flour
25
Capacity (t/h) Wheat, maize bran
20
ØD1 (mm)
250
ØD2 (mm)
410
ØD3 (mm)
250
H (mm)
900
Weight (kg)
30
